SLNM-118-AA, SLNM-63-AA, SLNM-98-AA, SLNM15-63-AA

Vestil Narrow Mast Powered Lift Stackers

Name: Vestil Narrow Mast Powered Lift Stackers
Brand: Vestil
Price: 6479.0 USD
Availability: InStock

Brand: Vestil SKU: SLNM-118-AA Only 1 left

Authorized dealer

$4,564.99 - $6,479.00

$6,479.00

$4,564.99 - $6,479.00

$6,479.00

Product Highlights

Narrow mast push-button lift
Nylon wheels
Charger and gauge

Ships in 6 business days

Quantity

Estimated delivery:

Ships direct from Vestil

Genuine, full warranty
30-day returns See the return policy
Only CA orders are taxed
Mon–Fri 9 AM–6 PM PT

Prefer to talk? Call a specialist (805) 261-2630

Sizing, shipping and volume pricing. Mon–Fri 9 AM–6 PM PT.

Instruction manual PDF Warranty PDF

Overview

Main Specifications

MPN SLNM-118-AA

Overall width 29 in

Overall length 65-1/2 in

Overall height 78 in

Individual fork width 4 in

Fork length 36 in

Assembled weight 700 lbs

Material Steel

Color / finish Black

Vestil Narrow Mast Powered Lift Stackers

Raise material under power on a narrow mast stacker suited to shipping and manufacturing areas. Push-button controls operate the lifting mechanism.

Nylon steering and load wheels support maneuvering, and a charger and charge gauge are provided. Capacity on the taller models depends on the lifting height.

Narrow Mast Powered Lift Stackers Features

Narrow mast powered lift
Push-button lifting control
Nylon steering and load wheels
Battery charge gauge

Warranty

Vestil 1-Year Limited Warranty

Vestil Manufacturing backs this product with a limited parts warranty against defects in material and workmanship. The warranty period starts on the ship date.

Original dynamic components (motors, hydraulic pumps, electronic controllers, switches and cylinders): 1 year
Wearing parts such as bearings, hoses, wheels, seals, brushes and batteries: 90 days
Vestil provides a replacement for a covered part. Labor and freight are not covered.
Misuse, improper maintenance, corrosion, shipping damage and unauthorized modifications void the warranty.

See the Warranty document on this page for the full terms.

Full Specifications

Specifications

Uniform Capacity at 0 - 63" (lb.)		1,500
Uniform Capacity at 63 - 118" (lb.)		1,000
Service Range (in.)		2 to 118
Adjustable Fork Spacing (in.)		8 to 27 (OD)
Adjustable Leg Spacing (in.)		40-1/8 to 50 (ID)
Overall Mast Height (in.)		78-1/2
Lift Motor		DC 12V / 1-3/10 KW
Battery		12V / 140 Ah
Battery Charger		12V / 6 amp
Raise Time w/ Load		5-9/10" / sec
Raise Time w/o Load		2-19/20" / sec
Lower Time w/ Load		4" / sec
Lower Time w/o Load		3-3/20" / sec
Power Source		Electric - Cordless
Maximum Travel Distance (in)		116
Leg Width (in)		4
Battery Charger Included		Yes
Horsepower (hp)		1/2
Maximum Amperage (A)		6
Phase		Single Phase
Number of Casters / Wheels		4
Rear Wheel Diameter (in)		5-9/10
Rear Wheel Material		Polyurethane
Front Wheel Diameter (in)		5
Front Wheel Material		Polyurethane

Shipping

Ship weight		912 lbs
Freight Type		LTL Palletized
Package Width (in)		65
Package Depth (in)		74
Package Height (in)		84
Freight Class		200

Warranty

Manufacturer Warranty		1 Year
Warranty Type		Limited - Parts
Manufacturer Warranty #2		90 Days
Warranty Type #2		Wearable Parts warranty

Size & Specification Comparison

All models: Material: Steel

Compare all sizes & specifications

Vestil Narrow Mast Powered Lift Stackers: specifications by model
Model	Overall width	Overall length	Overall height	Individual fork width	Fork length	Assembled weight	Color / finish
SLNM-118-AA	29 in	65-1/2 in	78 in	4 in	36 in	700 lbs	Black
SLNM-63-AA	29 in	65-1/2 in	78 in	3-1/8 in	30 in	504 lbs	Yellow
SLNM-98-AA	44-33/40 in	53 in	68-1/2 in	4 in	36 in	620 lbs	Yellow
SLNM15-63-AA	35-1/2 in	53 in	78-1/2 in	3-1/8 in	36 in	590 lbs	Black
