Vestil Powered Fork Reach Stacker

Name: Vestil Powered Fork Reach Stacker
Brand: Vestil
Price: 18899.0 USD
Availability: InStock

Brand: Vestil SKU: S-118-AA-FR Only 1 left

Authorized dealer

$18,899.00 - $18,899.00

$18,899.00

$18,899.00 - $18,899.00

$18,899.00

Product Highlights

Extendable powered forks
Powered drive and lift
Onboard charger

Ships in 6 business days

Estimated delivery:

Ships direct from Vestil

Genuine, full warranty
30-day returns See the return policy
Only CA orders are taxed
Mon–Fri 9 AM–6 PM PT

Prefer to talk? Call a specialist (805) 261-2630

Sizing, shipping and volume pricing. Mon–Fri 9 AM–6 PM PT.

Instruction manual PDF Warranty PDF

Overview

Main Specifications

MPN S-118-AA-FR

Overall width 57-7/8 in

Overall length 95 in

Overall height 79-1/4 in

Fork length 36-1/4 in

Assembled weight 1735 lbs

Material Steel

Color / finish Yellow / Black

Vestil Powered Fork Reach Stacker

Reach toward a load with extendable forks on a powered fork reach stacker. Powered drive and lift functions position material in distribution and shipping work areas.

Align the forks before extending them to the load, then move the secured material to the work area. An onboard charger, battery gauge and horn are provided.

Powered Fork Reach Stacker Features

Powered fork reach
Powered travel and lifting
Onboard charger
Battery gauge and horn

Warranty

Vestil 1-Year Limited Warranty

Vestil Manufacturing backs this product with a limited parts warranty against defects in material and workmanship. The warranty period starts on the ship date.

Original dynamic components (motors, hydraulic pumps, electronic controllers, switches and cylinders): 1 year
Wearing parts such as bearings, hoses, wheels, seals, brushes and batteries: 90 days
Vestil provides a replacement for a covered part. Labor and freight are not covered.
Misuse, improper maintenance, corrosion, shipping damage and unauthorized modifications void the warranty.

See the Warranty document on this page for the full terms.

Full Specifications

Specifications

Uniform Capacity Forks Retracted at 2" to 62" Raised Height (lb.)		1,500
Uniform Capacity Forks Extended at 2" to 62" Raised Height (lb.)		800
Uniform Capacity Forks Retracted at 62" to 118" Raised Height (lb.)		1,000
Uniform Capacity Forks Extended at 62" to 118" Raised Height (lb.)		600
Fork Width (in.)		26-3/4
Lowered Height (in.)		2-1/2
Raised Height (in.)		118
Width Between Straddle Legs (in.)		40 to 50
Fork Reach (in.)		25
Battery Quantity/Volts		(2) 12
Load Center (in.)		15-3/4
Required Isle Clearance (in.)		115
Power Source		Battery-operated
Maximum Travel Distance (in)		115-1/2
Adjustable Forks		Yes
Minimum Width Between Forks (in)		8-3/10
Maximum Width Between Forks (in)		26-3/4
Adjustable Legs		Yes
Leg Width (in)		4
Minimum Width Between legs (in)		40-1/8
Maximum Width Between legs (in)		50
Battery Charger Included		Yes
Horsepower (hp)		2
Voltage (V)		24
Number of Casters / Wheels		5
Rear Wheel Diameter (in)		4
Rear Wheel Material		Poly on Steel
Front Wheel Diameter (in)		6
Front Wheel Material		Poly on Steel
Additional Contents		Required Isle Clearance of 115 Inches.

Shipping

Ship weight		1816 lbs
Freight Type		LTL Palletized
Package Width (in)		64
Package Depth (in)		91
Package Height (in)		90
Freight Class		200

Warranty

Manufacturer Warranty		1 Year
Warranty Type		Limited - Parts
Manufacturer Warranty #2		90 Days
Warranty Type #2		Wearable Parts warranty
